terraform-aws-pmm-ecs¶

Terraform module for deploying Percona Monitoring and Management (PMM) on AWS EC2 with Docker.

Features¶

Production-ready PMM deployment on dedicated EC2 instance with persistent EBS storage
Automatic SSL/TLS with ACM certificates and DNS validation via ALB
Automated backups via AWS Backup with configurable retention
Auto-recovery for hardware failures with EC2 auto-recovery and CloudWatch alarms
RDS monitoring with automatic security group configuration for PostgreSQL and MySQL
Custom PostgreSQL queries with configurable collection intervals (high/medium/low resolution)
MySQL/Percona Server ASG monitoring via Lambda reconciler that automatically installs pmm-client on instances via SSM
Comprehensive CloudWatch monitoring with dashboard and alarms for instance, disk, memory, and EBS metrics
Auto-generated passwords stored securely in AWS Secrets Manager
PMM 3.x by default (PMM 2 EOL July 2025)

Prerequisites¶

The operational documentation uses CLI tools from infrahouse-toolkit (ih-secrets, ih-ec2, etc.). Install it on Ubuntu:

# Install dependencies
apt-get update
apt-get install gpg lsb-release curl

# Add InfraHouse GPG key
mkdir -p /etc/apt/cloud-init.gpg.d/
curl -fsSL https://release-$(lsb_release -cs).infrahouse.com/DEB-GPG-KEY-release-$(lsb_release -cs).infrahouse.com \
    | gpg --dearmor -o /etc/apt/cloud-init.gpg.d/infrahouse.gpg

# Add InfraHouse repository
echo "deb [signed-by=/etc/apt/cloud-init.gpg.d/infrahouse.gpg] https://release-$(lsb_release -cs).infrahouse.com/ $(lsb_release -cs) main" \
    > /etc/apt/sources.list.d/infrahouse.list

# Install
apt-get update
apt-get install infrahouse-toolkit

Quick Start¶

module "pmm" {
  source  = "registry.infrahouse.com/infrahouse/pmm-ecs/aws"
  version = "1.2.0"

  providers = {
    aws     = aws
    aws.dns = aws.dns
  }

  public_subnet_ids  = ["subnet-abc123", "subnet-def456"]
  private_subnet_ids = ["subnet-ghi789", "subnet-jkl012"]
  zone_id            = "Z1234567890ABC"
  environment        = "production"
  alarm_emails       = ["devops@example.com"]

  # Optional: RDS monitoring
  rds_security_group_ids = [aws_security_group.postgres.id]
}

After deployment, PMM is available at https://pmm.<your-zone>/.

Retrieve the admin password:

ih-secrets get <admin_password_secret_arn from module output>

Monitoring Percona Server ASG Instances¶

For MySQL/Percona Server instances running in Auto Scaling Groups, the module provides an automated Lambda reconciler. It runs every 5 minutes, installs pmm-client on new instances via SSM, and removes services for terminated instances.

module "percona" {
  source  = "registry.infrahouse.com/infrahouse/percona-server/aws"
  version = "0.6.0"
  # ...
}

module "pmm" {
  source  = "registry.infrahouse.com/infrahouse/pmm-ecs/aws"
  version = "1.2.0"

  # ... other configuration ...

  monitored_asgs = [
    {
      asg_name          = module.percona.asg_name
      service_type      = "mysql"
      port              = 3306
      username          = "monitor"
      security_group_id = module.percona.security_group_id
    }
  ]
}

Documentation¶

Architecture -- how it works, component details, security model
RDS Setup -- adding PostgreSQL/MySQL RDS instances to PMM
Percona Server Setup -- automated MySQL/Percona Server ASG monitoring via Lambda reconciler
Backup & Restore -- backup configuration and recovery procedures
Runbook -- operational procedures, maintenance tasks, Lambda reconciler management
Troubleshooting -- common issues and solutions
